AED69.00 AED89.00
| Load Type | inductive, fluorescent lamp, incandescent lamp, resistive |
|---|---|
| Rated current | 16 AX at 250 V AC 50/60 Hz |
| Part Number | E8333L1LED_DG |
| Activity | HDCWD |
| Clamping Connection Capacity | 3 x 2.5 mm² for solid cable(s), 3 x 2.5 mm² for stranded cable(s), 4 x 1.5 mm² for solid cable(s), 4 x 1.5 mm² for stranded cable(s) |
| Colour | dark grey |
| depth | 34.2 mm |
| device application | control |
| device mounting | flush, surface |
| Device Presentation | complete product |
| Embedding Depth | 24.5 mm |
| height | 86 mm |
| IP degree of protection | IP20 |
| Material | polycarbonate: grid plate, polycarbonate: base, polycarbonate: dolly, polycarbonate: frame, polycarbonate + GF 20 %: actuator |
| Maximum Ambient Air Temperature for Operation | 35 °C |
| Number of Gangs | 3 gangs |
| Number of Rocker | 3 |
| operating altitude | 2000 m |
| product or component type | switch |
| range | AvatarOn |
| relative humidity | 0-95 % |
| Switch Function | 1-pole 1-way |
| width | 86 mm |
| standards | GB 16915.1 |
| local signalling | off: LED indicator, LED |
| environmental characteristic | UV resistant |
| connections – terminals | brass terminal |
